Sizes
Combined Soffit and Fascia Cladding is available in almost any size, below are some of our standard maximum girth sizes:
- 415mm
- 500mm
- 615mm
- 625mm
- 750mm
- 1000mm
Fittings
Brackets
Colours and Finishes
Benefits
Downloads
Gallery

Combined soffits and fascias are uniquely designed, specified and fabricated for individual projects. They can be wrapped as a cladding around a concealed gutter, have an external gutter or can be a stand-alone soffit and fascia.

Aluminium combined soffit and fascias are highly adaptable and being project specific we can manufacture virtually any profile, shape and size along the roof edge.
This Combined Soffit and Fascia integrates perfectly with Guttercrest’s external gutters or concealed internal guttering, rainwater downpipes, and our range of aluminium eaves products, coping and cappings.
Venting can be incorporated into the combined eaves soffit and fascias.
V-Ribbing to either or both the soffit and fascia gives a feature plank look like timber tongue and groove planking or weatherboard cladding. It also strengthens the aluminium soffit and fascia panels.
Special fabrications and architectural detailing.
Please Note: Due to our ongoing product development policy, we reserve the right to alter specifications without prior notice.
Combined Soffit and Fascia Cladding is available in almost any size, below are some of our standard maximum girth sizes:
Our aluminium combined soffit and fascia fitting are manufactured in-house and our range includes standard and non-standard angles, stop ends, raking angles, apex angles, stepped angles, doglegs, and junctions to bargeboards and verges.
If the project requires a curved aluminium fascia board, radius fascia cover or radii fascia cladding, to either a true or facetted curve, our primary duo fascia system is a great solution where horizontal, vertical, and most complex curves are achievable.
Combined soffits and fascias can be fixed to many types of background, varying from timber carcassing to metal aluminium or galvanized steel carcassing and sub-framing. The correct carcassing design will shorten the installation time. Bespoke, purpose-made brackets can be designed and manufactured to support the aluminium fascia cladding along with any integrated soffits and gutters.
All our aluminium combined soffits and fascias are available polyester powder coated in a wide array of colours and finishes including the full range of RAL colours, BS colours, Heritage textured finishes, metallic finishes, and anodised coating.
We can also source special colours and finishes to match your project requirements or we can supply our aluminium combined sofftits and fascias in the standard mill finish.
Combined soffits and fascias are uniquely designed, specified and fabricated for individual projects. They can be wrapped as a cladding around a concealed gutter, have an external gutter or can be a stand-alone soffit and fascia.
Please Note our standard Black is RAL 9005 & Standard White is RAL 9910G.
